RB-60
Receding Head Die-Cutting Machine RB-60
- Product Description
- Cutting Force 60 tons
- Max. Cutting stroke 110mm
- Open daylight 50-160mm
- Main motor 7.5HP
- Machine bed 900D*1600W mm
- Effective cutting area #1 880D*1580W mm
- Effective cutting area #2 880D*1420W mm
- Machine dimension 2640W*2085D*1870H mm
- Weight approx. 5000 Kgs
*Effective cutting area #1: Without die rails and pad shifter.
*Effective cutting area #2: With either die rails and pad shifter.
*The above are the basic standard specifications. Special specification and CE safety version are available upon request.
